New Afton Mine delivers on ISO 50001
New Gold gets energy savings while enhancing corporate responsibility
New Gold is a leading international gold producer. When the company hired a BC Hydro-funded Industrial Energy Manager in 2011 and officially opened New Afton mine 15 km west of Kamloops in 2012, it was a chance to work with BC Hydro to pursue the first ISO 50001 certification at a mine in North America.
BC Hydro's Strategic Energy Management (SEM) Program helps organizations staff and deliver on a strategic approach to managing energy. ISO 50001 takes energy management to the next level with an external validation process, a focus on operations and controls and the requirement to understand and document all energy management systems.
While many organizations have made great strides in reducing energy consumption, they're now asking themselves whether their project-based approach to energy savings will reach their goals.
Often, the answer is to introduce a systematic approach to managing energy, also known as an energy management system. Taking that approach while establishing sound business processes is key to achieving continual improvement in an organization.
In summer 2011, the International Standards Organization released the ISO 50001 energy management system standard, which formalizes energy management and provides a global benchmark. This standard has been adopted by the Canadian Industry Program for Energy Conservation among other national organizations.
The business case: 'A 1% reduction in energy costs is worth hundreds of thousands of dollars a year '
With gold prices dropping from $1,900 per ounce in 2011 to under $1,200 in 2015, cost reductions in production and operations are critical in the mining business. To stay competitive, producers must find improvements that require minimal capital investment through innovation, creativity, and improved systems.
"Mining is energy intensive," says Andrew Cooper, New Afton's energy specialist. "At the New Afton Mine, a one per cent reduction in energy costs is worth hundreds of thousands of dollars a year. With low commodity prices and increasing offshore competition, energy-efficiency improvement is one of the few places where we find increases in profitability."
ISO certification helps achieve consistent cost reductions. From a social responsibility perspective, ISO fits well with New Gold's corporate social responsibility program as well as the company's Towards Sustainability Mining initiatives.
ISO 50001 also provides a vehicle to achieve the company's energy management vision: to have energy management practised by all employees on a day-to-day basis.
A key element of the value ISO delivered to New Afton stemmed from the accountability that it created. Internally, having an outside organization verify the site's energy management system meant the entire team had to sit down and work with an auditor to assess their organization.
Externally, it offered value through recognition and verification of the site's commitment to social responsibility and sustainable mining.
Says Cooper: "ISO certification means a few things: it's verification that we are serious about managing energy; it's in line with our vision around energy management and our values at the mine; and in addition to assisting with cost reduction and GHG reduction, it also demonstrates a commitment to social responsibility and sustainable mining."
Connecting ISO to other corporate priorities
Energy-efficiency projects often result in operational performance improvements. At New Afton, every energy efficiency project completed has had additional benefits for operations (production), safety and the environment.
Increasing efficiency with process improvements on an ongoing basis is part of the culture of the company, so energy efficiency connects well to this focus.
"I'm always very conscientious of the fact that the primary objective of the mine is to produce copper and gold concentrate," says Cooper. "If something's just going to save energy and not help with production, people are going to lose interest.
"For example, we did a flotation blower improvement project, where we saved a lot of energy. At the same time, we improved the operation of the circuit that increased production, the air flow to the flotation process is smoother, and since the operators don't have to run around and adjust valves, there's a safety improvement. On top of that, we were able to reduce the noise of the equipment, another health and safety benefit."
BC Hydro's SEM Program and ISO 50001 complement each other, with both integrating energy management into manegement practices. ISO then ensures these are sustained through regular external validation.
Based on New Afton Mine's experience, the two energy management programs compare in the following ways.
|Features||BC Hydro's SEM Program
|Focus||Identify and implement energy projects within a comprehensive energy management framework.
||Understand energy use for Significant Energy Uses (SEU).|
|Results||Expected energy savings for each two-year contract.||Energy performance is measured against Energy Performance Indicators (energy objectives and targets determined by the organization).|
||Quarterly update reporting to BC Hydro.||Annual reporting with third party verification.|
||Energy savings verified through measurement and verification of capital projects. Self-reporting of other SEM activities.||External audits of processes and procedures as well as methods for determining Energy Performance Indicators and measurement and verification.|
||Financial support by BC Hydro for program initiatives, including the Industrial Energy Manager role, Energy Coaching and Employee Engagement support.||Co-funding available from NRCan to support ISO certification (was $25,000 for New Gold, additional funding now available). BC Hydro funding support for some initiatives related to ISO.|
||Provides access to funding opportunities for studies and incentives for retrofit projects.||No funding provided for projects.
||Strong support from BC Hydro account management, engineering and marketing departments. Energy Management Assessment and Audits supported by BC Hydro were aligned with ISO requirements.||No direct support for ISO 50001.
|What's not included
||Different focus compared to ISO 50001 on operational controls and how to manage them.||No external reporting during the year. The annual Energy Review takes the place of a bi-annual Energy Management Assessment.|
"The BC Hydro program is second to none; there are not many utilities that offer the support it offers," says Cooper. "ISO 50001 may not have been possible without the energy project funding and coaching support from BC Hydro that enabled it to happen."
Getting to ISO 50001: the implementation phase
A history of energy management success makes ISO 50001 easier to sell
Since the launch of its energy management program, New Afton has built from the ground up, a different approach than that taken in some companies where the mandate for energy efficiency starts at a high level and is pushed down through the organization.
By starting with the operators on the floor and getting proof of concept, Cooper has been able to use initial energy project success stories to secure support from the executive team to pursue ISO 500001 certification.
Five steps to implementing ISO
New Afton followed five steps, many of which were in place from their SEM Program participation, to achieve ISO 50001 certification:
- Gain support from senior management for certification, a task made easier by New Afton's previous energy management success,
- Measure energy performance:
- Energy Management Information System (EMIS): workshop, system design, vendor selection, set up;
- Process Integration (PI): server installed and data stored in database;
- EAC: Identified Energy Account Centres: Milling (5), Mining (5), Crushing and Conveying.
- Develop an energy policy that calls for staff commitment to continually improve energy performance.
- Develop and implementd training and engagement plans: "When you have a 24/7 operation with different departments and different crews, the energy team has to spend a lot of time spreading the word, training people and promoting the program."
- Prepare documentation: prepared for the auditor; not just program components but proof of what is being done as well.
Challenges to implementation
The biggest challenge for New Afton lay in operational controls and maintenance, and getting people to remember what's expected of them from an energy management perspective.
To tackle the challenge, Cooper has spent countless hours talking to crews. He has daily conversations with people who want to talk about energy; this aspect of the work is constant and ongoing.
"All the interaction with the crew is important because it's people, not systems, that manage energy," he says. "This is how I communicate specifics of SEUs [Specific Energy Uses], the operational requirements of their department relating to energy management and how operators get to know exactly what they need to do to operate with optimal efficiency.
"They are not going to know that unless you get in front of them."
With more than 152 electrical sub-meters and five gas sub-meters, another challenge to implementing ISO was the time required to install sub-metering and ensure that each meter was communicating properly with the Energy Management Information System (EMIS).
Building on ISO 14001
New Afton is certified to the environmental standard ISO 14001. However, as they entered the ISO 50001 certification process, Cooper and his Energy Team were surprised to find there isn't as much overlap as they anticipated.
ISO 50001 addresses a key energy management section in the 14001 system, but the most similar aspect between the two standards is the document management and control system. That being said, Cooper points out that, "it made an easier case for 50001 because people were already using ISO, so it wasn't a new thing we were trying to implement."
Incremental value proposition for ISO certification (Beyond SEM)
The external accountability aspect of ISO 50001 helped build energy management into the New Afton's systems and the culture of the company. Energy is a topic discussed during daily staff huddles and Cooper was given a platform at the mine's quarterly meetings and in the site newsletter.
To maintain certification, the company also includes energy performance improvement objectives in the organization's business planning process and uses a systematic approach to consider energy efficiency in new design or upgrades.
"[With ISO 50001] everything's covered, even down to the operational aspects of managing energy. You have to identify each Significant Energy Use (SEU), develop training programs for each SEU, do operator training on specifics of energy within each SEU, develop significant deviations and targets for each SEU and tell people how they need to act in case of significant deviations for each SEU."
Results and benefits
Results from the ISO certification process
With a strong Strategic Energy Management Program in place, New Afton Mine used the ISO 50001 certification process to reinforce good energy management practices and achieve a number of impressive results:
- ISO certification in March 2014.
- Energy performance improvement initiatives implemented in 2014 yielded savings equivalent to 7.3% of 2013's total energy consumption.
- The New Afton operation was originally designed to process 11,000 tons per day (4 million tons per annum) of ore at full capacity. With the focus on energy efficiency and process improvements, the mine has increased production to more than 5 million tons per annum – 25% above design.
- Projects completed in 2014 include:
- Conveyor shut down during shift changes identified by staff.
- Mill flotation blower control upgrade.
- Underground compressed air compressor relocation.
- Increase in the port size of SAG mill discharge grate.
- Surface and mill lighting upgrades.
- As a result of its hard work, New Afton mine was awarded NRCan's CIPEC Leadership Award for Energy Performance Management in May 2014.
The benefits of participating in the ISO certification process and having a strong Strategic Energy Management Program in place have been numerous for New Afton.
- The mandated regular management reviews of energy ensure that energy management remains a focus with senior management at the mine.
- By participating in the process, New Afton has built a strong energy team with representatives from across the mine.
- Engagement of operators and staff across the site has improved. Staff are more aware of energy management opportunities and their role in achieving results.
- Energy performance improvement projects have resulted in a number of spinoff health and safety benefits.
Energy data is used instead of run hours for some reliability-centred maintenance. Energy data shows how hard equipment is working as opposed to how long it is running for.
- The annual checks conducted by a third party provide rigour to the program as well as validation that "we are doing the right things." They are also an opportunity for the mine to reinforce and renew their
commitment by maintaining their certification.
- ISO 50001 ensures that "you can't let up on energy management: ISO requires you to stay on top of all aspects of the program and continually improve. And that's a good thing."
|You have to sell the benefits of the system||
|Look beyond energy savings||
|The need for outside assistance||
How can ISO 50001 help other BC Hydro industrial SEM participants achieve their energy management goals?
New Afton took the first step with SEM, providing a strong foundation for success in energy management. Going beyond SEM to 50001 provided additional benefits. These included the additional traction gained through an external verification process, the greater structure and systems required to achieve certification and the focus on detail in the energy management program.
Says Cooper, "You've got to have a vision and it has to be inspiring, even if it's only for the person managing the project. It's got to say what you want to achieve, where you want to get to, what it's going to do for you and what is the long term goal? As part of our SEM Program, we put ours together into a policy and in a lot of ways it's become what we do now. The vision is still relevant today. I saw ISO 50001 as a vehicle to achieve our vision."
Looking to the future
New Afton will continue to promote energy management as a core activity. They will use the EMIS to make energy management visible to all levels of the organization and to optimize energy use. A key area for improvement is to solidify the ISO 50001 systems, ensuring energy management is integrated into everyone's work process, not dependent on a single person or department.
Finally, the success of the energy management program at New Afton will help to bring the experience to other New Gold facilities.
- New Gold is a leading intermediate-size gold producer. Their New Afton operation was originally designed to process 11,000 tons per day (4 million tons per annum) of ore at full capacity, recovering copper, gold and silver.
- Commercial production started in July 2012 at New Afton, 15 km west of Kamloops, B.C. Processing includes conventional crushing, grinding, and concentration processes, with mineral separation by gravity concentration and differential flotation.
- Annual production at New Afton in 2014 was 104,589 ounces of gold, 200,000 ounces of silver and 84.5 million pounds of copper.
- A BC Hydro funded energy manager has been in place since October 2011.
- The Strategic Energy Management (SEM) approach was in place at the site when certification was pursued.
- New Afton is the first mine in North America to achieve ISO 50001 certification.
